Codice: MSO8064
Perché acquistare da noi?
- Garanzia di 36 mesi su tutti gli strumenti
- Oltre 40 anni di esperienza
- 15.000+ clienti soddisfatti
- Assistenza rapida grazie al laboratorio interno
Oscilloscopio digitale, banda passante 600MHz, 4 canali analogici e 16 digitali , display da 10.1 pollici touch screen , acquisizione ad oltre 600000 forme d'onda/sec. Integra 7 strumenti indipendenti in uno.
Specifiche tecniche:
|
Bandwidth
|
600MHz
|
|
Analog Channels
|
4 |
| Digital Channels | 16 |
|
Vertical Sensitivity
|
1 mV/div - 10V/div
|
|
Real-time Sample Rate
|
10 GSa/s
|
|
Memory Depth
|
500 Million Points
|
|
Waveform Acquisition Rate
|
≥600,000 wfms/s (Waveforms per Second)
|
|
Interface
|
Multiple interfaces available: USB HOST&DEVICE, LAN(LXI), HDMI, TRIG OUT, and USB-GPIB
|
|
Vertical Resolution
|
8 bits
|
| No. of Math Functions | 4; 4 math functions available to be displayed at a time |
|
Operation
|
A+B, A-B, A×B, A/B, FFT, A&&B, A||B, A^B, !A, Intg, Diff, Sqrt, Lg, Ln, Exp, Abs, AX+B, LowPass,
HighPass, BandPass, and BandStop |
|
Cursor Measurements
|
Manual, Track and Auto Measure modes
|
| Several modules | Digital Oscilloscope , Digital Voltmeter , Logic Analyzer , Spectrum Analyzer , Arbitrary Waveform Generator (Option) , High-precision Frequency Counter and Totalizer , Protocol Analyzer (Option) |
